1 in stock
ℹ️ We are NOT an authorized distributor for Euchner
225 $
Ready for immediate dispatch.
Manufacturer: EUCHNER
Type: LIMIT SWITCH
Model: SN02-R16-502
Connection cross section: 0.34 … 1.5 mm²
Rated insulation voltage: 250 V
Rated impulse withstand voltage Uimp: 2.5 kV
Utilization category:
-DC-13 6 A 24 V
-AC-15 6 A 230 V
-AC-12 8 A 250 V
Switching current: min. at DC 12V min. 10 mA
thermal rated current Ith: 8 A
Approach speed: 0.01 … 80 m/min
Number NC contacts: 2
Number of switching elements: 2
Number of NO contacts: 2
Actuating force: min. 20 N
Degree of protection: IP67
Plunger spacing: 16 mm
Ambient temperature: -5 … +80 °C
| Manufacturer | Euchner |
|---|---|
| Model | |
| Condition |
We offer a wide range of spare parts including automotive, industrial, electronic, and appliance parts, both new and used.
You can use our search bar at the top of the page or browse through categories to find the specific part you need.
Used parts come with 2 month warranty.
