Manufacturer: TELEMECANIQUE
Type: SAFETY INTERLOCK SWITCH
Model: —
Rated Insulation Voltage: 250 V
Rated Impulse Withstand Voltage (Uimp): 2.5 kV
Utilization Category AC-15: 4 A / 230 V
Utilization Category DC-13: 4 A / 24 V
Thermal Rated Current: 4 A
Approach Speed (max.): 20 m/min
NO Contacts (Door Position): 1
Positively Driven Contacts (Door Position): 3
Extraction Force: 35 N
Actuating Force: 35 N
Retention Force: 8 N
Actuation Frequency (max.): 1200 1/h
Degree of Protection: IP67
Ambient Temperature: -25 … +80 °C
