2 in stock
ℹ️ We are NOT an authorized distributor for PILZ
Ready for immediate dispatch.
Manufacturer: Pilz
Model: PNOZ X2.1 24VAC/DC 2n/o
Type: Safety Relay
Part No.: 774306
Supply voltage: 24 V
Type of supply voltage (U1): AC/DC
Power consumption AC: 4.5 VA
Power consumption DC: 2 W
Number of inputs: 2
Number of semiconductor outputs: 0
Voltage AC1 safety contact: 240 V
Max. current AC1 safety contact: 6 A
Voltage DC1 safety contact: 24 V
Max. current DC1 safety contact: 6 A
Voltage AC15 safety contact: 230 V
Max. current AC15 safety contact: 5 A
Voltage DC13 safety contact: 24 V
Connection terminal: Screw terminal
Terminal style: Fixed
Ambient temperature: -10 … 55 °C
| Weight | 0.200 kg |
|---|---|
| Manufacturer | PILZ |
| Model | |
| Part Number | 774306 |
| Condition |
